Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Hunan Jinlian Cloud Information Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Series : Micro Load Cell

Features : Aluminum alloy sensor

Mounting Type : Fixed installation

Description : Can be consulted, SC635 micro load cell

Model Number : SC635

Type : Load Cell

Place of Origin : Guangdong, China

Brand Name : SNC

Use : PRESSURE SENSOR

Theory : Resistance Sensor

Output : Analog SENSOR

Capacity : 1KG-50KG

Rated Output : 1.0±0.2mV/V

Comprehensive error : 0.05 %F.S

Non-linearity : 0.05%F.S

Accuracy class : 0.05%

Creep : 0.05 [(3 min)% F.S.]

Input impedance : 1000±50 Ω

Safe overload : 120%F.S

Cable : 0.8 x 220mm

Connection : Excitation: Red+, Black- Signal: Green+, White-

MOQ : 10 pieces

Price : $2.80/pieces 10-499 pieces

Contact Now

weighing Scale Single Point Load Cell Miniature load cell sensor 2 Kg 5 Kg 10 Kg 15 Kg 20 Kg 50 Kg

Product List

Sensorcon Product Lists
Strain Gauge Load Cell Torque Sensor Display
Linear Strain gauge-AA Wireless sensor Slip ring rotary torque sensor Platform scale display
Half bridge strain gauge-BB,HA,GB,FB Micro load cell Contactless rotary torque sensor Truck scale display
Shear/torque strain gauge-AB,HA Single point load cell Static torque sensor Controller
Full bridge strain gauge-EB, FG,FD Button load cell Meters Junction box
Tee Rosettes strain gauge-CA,BA Shear beam load cell Coupling Big screen display
Round type strain gauge S type load cell Amplifier
Semi-conductor strain gauge Column load cell
Bridge type load cell
Product Description

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Parameters

Capacity 1kg-50kg
Rated Output 1.0±0.2mV/V
Comprehensive error 0.05 %F.S
Non-linearity 0.05%F.S
Hysteresis 0.05%F.S
Repeatability 0.05%F.S
Creep 0.05 [(3 min)% F.S.]
Zero output -0.15~+0.05 m V/V
Temp. effect on zero 0.3 (%F.S/10℃)
Temp. effect on span ≤0.15 (%F.S/10℃)
Input impedance 1000±50 Ω
Output impedance 1000±50 Ω
Insulation resistance ≥2000 MΩ
Operating compensated range -10~+40
Recommended excitation voltage 3-10 VDC
Safe overload 120%F.S
Ultimate Overload 150%F.S
Cable Φ0.8 x 220mm
Connection Excitation: Red+, Black- Signal: Green+, White-

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Load cell Accessorie

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Related Products

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Packaging & Shipping

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

Company Information

Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

Aluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate WeighingAluminum Alloy Sensor Body Scale Miniature Weight Sensor Single Point Load Cell 1KG-50KG for Accurate Weighing

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
